Description
Passive Crown System: Automatically compensates for roll deflection—from thin sheets up to 1/4″ plate—without crowning or shimming
Roll Material: Flame‑hardened and polished 1045 carbon steel rolls
Drive System: Hydraulic motors (LSHT type), instant start/stop/reverse, synchronized top and bottom rolls
Speed: Variable up to 22 ft/min
Controls: Beta 4.2 console with 3 digital readouts for lower roll positions
Electrical Package: NEMA 12 cabinet, 230/460 V 3‑phase, PLC-compliant, variable‑frequency drive
Bearings & Construction: SKF spherical roller bearings; fabricated steel frame designed to sit on a level floor
Pre‑bend Capacity: 1/4″ (0.250″) × 5′, meaning it can prebend plate up to 1/4″ thick across the full 5′ width
