Description
Cutting Capacity:
Rectangle (Nominal 3° Cant): 14.5″ × 20″
Round (Nominal 3° Cant): 14.5″
Blade at 45°: 14.5″ × 13.5″
Blade at 60°: 14.5″ × 8.75″
Blade Drive: 5 HP
Speed Range: 60 to 400 FPM
Tilting Column: Miter cutting up to 60° left and right
Feed Force: Direct force sensing electric ball screw feed
Blade Size: 16′ long × 1.25″ wide × 0.042″ thick
Equipped With:
PC3 Programmable CNC Control
