Description
90 Degree Capacity:
25.6″ Diameter Round at 90 Degrees
25.6″ x 43.0″ Rectangle at 90 Degrees
45 Degree Capacity:
25.6 Diameter Round at 45 Degrees
25.6″ x 25.6″ Rectangle at 45 Degrees
60 Degree Capacity:
25.6″ Diameter Round at 60 Degrees
25.6″ x 15.7″ Rectangle at 60 Degrees
Blade Size: 28′-6.5″ x 2.13″ x .063″
Blade Speed: 98 to 361 SFPM
Hydraulically Control Blade Tension
Fluid Capacities:
Coolant: 31.7 Gallon
Hydraulic Fluid: 21.1 Gallon
Transmission Fluid: 1.3 Gallon
Load Capacity: 4400 lbs
Pressure Settings:
Hydraulic Pressure: 1067 PSI
Blade Tension: 39825 PSI
