Description
Power supply: ~3x480v/ 60 hz or other
Maximum height of a section: 8″
Maximum length of a section: 20′
Positioning accuracy of X/Y axes: ±0.05 mm
Positioning repeatability of X/Y axes: ±0.03 mm
Nominal power output: 3.0 kW
Power consumption: 24.0 kW
Source brand: MAX Photonics and Raycus as available options for selection
Ingress protection rating: IP54
Mild Steel: Recommended up to 20 mm; maximum 22 mm
Stainless Steel: Recommended up to 8 mm; maximum 10 mm
Aluminum: Recommended up to 6 mm; maximum 8 mm
Brass: Recommended up to 5 mm; maximum 6 mm
