Description
Load Capacity: 3,400 lbs
Load Center: 24 inches
Power Source: Electric (36V or 48V battery options)
Drive Motors: 4.8 hp (36V) or 5.0 hp (48V) AC motors
Control Type: MOSFET Transistor
Travel Speed (Full Load): 9.9 mph
Lift Speed (Full Load): 71 fpm (36V), 89 fpm (48V)
Gradeability (Full Load): 24%
Mast Options:
2-Stage Mast: Lift heights ranging from 107.5 to 158.5 inches
3-Stage Mast: Lift heights ranging from 147 to 237.5 inches
Overall Dimensions:
Length to Forkface: 69 to 77.2 inches
Overall Width: 41.5 inches
Overhead Guard Height: 80.9 inches
Weight (Without Battery): Approximately 5,190 lbs
Needs new Battery
