Description
Electrical Requirement: 460-480V, 3 phase, 60HZ
Laser source: Fiber laser
Laser power: 6000W
Cooling type: Water cooler
Laser wavelength 1080 nm
Working area: 51″×51″
External dimension: 107″x 85.4″x 81.9″
Maximum Cutting Speed 30m/min
Maximum Operation Speed 40m/min
Repeat Positioning Accuracy ±0.03 mm
Machine weight: 3,747.8 lbs
Equipped With
Software CypCut CAD/CAM
Compatible with 32-bit or 64-bit Windows10/11. Machine/PC Connection USB / FLASH / LAN
Control Interface Computer based on the Windows systemCutting Accuracy ±0.05 mm/m
Auxiliary Gas Air, Oxygen, Nitrogen
