Description
Model: 306-90
Electrics: 440 Volt, 3 Phase, 60 Cycle, 16 FLA, 120 Volt Control Circuit
Specifications and Features:
– Braking Capacity: 90 Tons
– Distance Between Columns: 78″
– Bed Length: 8′ (96″)
– Ram Adjustment: 5″
– Stroke of Ram: 3″
– Shut Height (Stroke Down, Adjustment Up): 12″
– Throat Clearance: 8-1/2″
– Back Gauge: 20″ Travel (approx.)
– Automatic Lubrication System
– Foot Pedal
Overall Dimensions (approx.): 100″ x 72″ x 110″
Weight (approx.): 17,000 lbs.
