Description
Capacity: 600kN (135,000 LB) Compression
490kN (110,000 LB) Tension
Power Stroke: 12″
Other Stroke Lengths Are Optional
Position Resolution: 1 um (micrometer)
Speed(max): 15 in/min at forces below 300kN Fast approach and light pressing
4 in/min at forces up to 600kN – Controlled speed for high-force pressing operations
Column Separation: 30″
Column Diameter: 3″
