Description
Round Tubing: 0.75″ to 6″ diameter
Square/Rectangular Tubing: 1″ to 4″
Angle & Channel: 1″ to 4″
Maximum Hypotenuse: 6.375″ (e.g., 6″ x 2″ or 5″ x 3″)
Material Thickness: 1/32″ to 5/8″
Maximum Material Length: 24 feet
Maximum Material Weight: 400 lbs
Bend-Tech
Cutting Tolerance: ±0.010″
Bend-Tech
Cutting Speed:
Plasma Cutting: Up to 120 inches per minute
Rapid Travel: Up to 1,100 inches per minute (X-axis), 30 RPM (Y-axis)
Equipped with:
Hypertherm Powermax45
Plasma Torch: For cutting profiles and holes
Marker: For bend locations, part numbers, and text
Engraver: For detailed markings and identification
Laser Pointer: For accurate job alignment
Surefire CNC by Weldclass
Material Handling:
Self-centering 4-jaw chuck
Adjustable front gate with vice-like jaws
Automated material support lift for maintaining level cuts
Software:
Bend-Tech Dragon Software Suite
Design Capabilities: Import STEP and IGES files from CAD programs like SolidWorks, AutoCAD, and Tekla
CAM Processing: Converts designs into CNC-ready files
Machine Control: Full control over machine axes, speed, and job execution
G-Code Viewer: Visualize each action in detail
System Requirements:
Operating System: Windows 7, 8, 8.1, 10, or 11
Processor: 1 GHz Dual-Core or higher
RAM: 4 GB
Graphics: OpenGL 1.3 compatible
.NET Framework: 3.5 SP1
Internet Connection: Required for activation and periodic update
Machine Footprint:
Shipping Dimensions: 10′ (L) x 5.5′ (W) x 7′ (H)
