Description
Pressure Beam Type: Rollers
Pre-Milling Station: 2 Motors
Glue Station
Pressure Rollers: 4
End Trimming Station: Straight & Bevel (2 motors)
Rough Milling Station: 2 Motor
Fine Milling Station: 2 Motor
Corner Rounding Station: 2 Motor
Flat Scraping Station: Top & Bottom
Profile Scraping Station: Top & Bottom
Buffing Station: Top & Bottom
Heat: Top & Bottom
Panel Height: 10-50 mm
Edge-banding Material Height: 13-55 mm
Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm
Max. Edge Thickness w/Trimming Unit: 8 mm
Max. Edge Thickness w/o Trimming: 3 mm
Max. Section of Solid Wood: 8 x 55 mm
Panel Protrusion from Track: 25 mm
Min. Panel Length: 150 mm
Min. Panel Width (150mm Length): 85 mm
Min. Panel Width (250mm Length): 55 mm
Chain Feed Speed: 12 m/min
Dimensions: 18′ L x 4′ W x 5′ H
Weight: 4,000 lbs
Electrical: 230 V 3 Phase
