Description
Chuck Diameter: 16″
Swing Inside Splash Guard: Maximum 21″
Range: 20″ Diameter x 9″ Vertical
Wheel Size: 10″ dia. x 4″ x 8″
Wheel Speed 1500 RPM
Chuck Speeds (4): 12 – 20 – 35 – 53 RPM
Power Down Feeds (Variable): 0.076 – 1.47 mm/min (w/ auto-stop)
Maximum Downfeed before stop operates: 1.219 mm
Vertical Travel of Wheelhead: 11″
Wheelhead Motor: 15 HP
Table Drive Motor: 1 HP
Wired: 220/440/3/60
Approximate Coolant Tank Capacity: 75 Gallons
Approximate Coolant Flow: 16 GPM
Chuck Height Above Floor: 37″
Approximate Dimensions: 80″H x 50″W x 91″H
Approximate Weight: 6,500 Lbs.
