Description
Specifications (subject to buyer verification):
Hydraulic Chuck Diameter (double chuck): 8″
Swing Over Bed: 10″
Turning Diameter: 8″
Work Piece Length: 25″
X-Axis: 8.6″
Z-Axis: 21.6″
Spindle Bore: 2.56″
Bottom Turret Tool Changer: 12
Upper Turret Tool Changer: 12
Max Spindle Speed: 5000 RPM
Main Motor: 40 KW
Power: 400V/230/3Ph/60Hz
Control: Siemens
Approx Weight: 16,500 LBS
Approx Dims: 162″ x 121″ x 110″
