Description
Pallet Size: 19.7″ x (2)
X-Axis Travel: 33.5″ (850 mm)
Y-Axis Travel: 27.6″ (700 mm)
Z-Axis Travel: 29.5″ (750 mm)
Pallet Index: 1 Degree
Spindle Speed: 14,000 RPM
Spindle Taper: Big Plus, CAT-40 DIN 15
Spindle Motor: 22/18.5 KW
Spindle Torque: 68.7 ft. lbs.
Spindle Center to Tabletop: 2″ – 29.5″
Spindle Nose to Table Center: 5.9″ – 35.4″
Tool Storage Capacity: 170
Pallet Change Time: 7.5 Seconds
Pallet Load Capacity: 1102 lbs.
Max Workpiece Size (Dia / Height): 31.5″ / 36.6″
Max Tool Diameter: 3″ / 5.5″
Max Tool Length: 15.7″
Max Tool Weight: 22 lbs.
Power Source: 3 Ph, AC 220V, 60 Hz
Approx. Machine Dimensions (L x W x H): 194″ x 108″ x 119″
Approx. Machine Weight: 33,069 lbs.
Equipped With:
FANUC 31iA CNC Control
PC/MCIA Interface
Number of Tool Offsets 200 Pairs
Helical Interpolation
Rigid Tapping
Coolant Thru Spindle
Tool Life Management
Spindle Chiller Unit
Manual Pulse Generator
