Description
Circular Blade Size: 21.65″
Blade Speed: 3,400 RPM
Construction: Cast (head frame, saw arm, etc.)
Feed System: Pneumatic
Blade Pivot: (±) 67.5° from 90° with digital display – Manually Adjusted
Blade Tilt: between 90° and 45° to the right with digital display
Equipped With:
– Pulse Spray Blade Lubricant System
3HP Chip Collection System
Programmable Pivot and Title Control
– AMS 200 Length Measurement system (right side connecting plate)
– Gravity Roller Stock Table (10’x15″)
– High Performance Cutting Fluid
– Two Hand Safety Control
– Steel Safety Hood with Plexiglass Window Insert
– Vertical Pneumatic Clamping
– Chip Collection Ports (1 Upper, 1 Lower)
– Air Filter – Regulator Unit
