Description
Max. Bar Length: 7600mm
Working Direction: Right to Left or Left to Right (switchable)
Max. Profile Cross-Section: 200 x 160 / 160 x 200 mm
Min. Profile Cross-Section (depending upon gripper position): 30 x 10 mm
Finished Part Length: 250-4,600 mm
Max. Spindle Speed: 24,000 rpm
Machining Stations
Axes: 4
Router Spindles: 4
Sawing Station
Axes: 2
Saw Blades (diameter): 1 (650 mm)
Sawing Angles: 45°-135° (pivoting)
Outfeed Conveyor
Lifting Stations: Yes
Number of Swing Arms: 8
Outfeed Conveyor Width: 4,000 mm
