Description
Max Swing Over Bed 20″
Max Swing Over Carriage 9.5″
Chuck Size 8″
Max Distance Between Centers 20″
Max Turning Length 24″
X-Axis (Cross Travel) 8.45″
Z-Axis (Longitudinal Travel) 20″
X-Axis Rapid Traverse Rate 400 IPM
Z-Axis Rapid Traverse Rate 400 IPM
Number of Tool Turrets 1
Turret Tool Positions 10
Spindle Nose A-6
Spindle Bore 3″
Bar Capacity 2″
Spindle Speed Range 0-3,750 RPM
Spindle Horsepower 15 HP
Electrics 208/230/3/60
Approximate Machine Dimensions 126″ x 70″
Approximate Machine Height 70″
Approximate Machine Weight 9,000 LBS
Run Time: 10,265
Machine only cut plastic its whole lifetime. Never saw a day of metal.
