Description
X-Axis Travel: 20″
Y-Axis Travel: 14″
Z-Axis Travel: 20″
Rapid Traverse Rates: 1,000 IPM
Cutting Feed Rate: Up To 833 IPM
Spindle Taper: CAT 40
Spindle Speed: 0–7,500 RPM
Spindle Motor: 20 HP
Pallet System: Dual 180° Pallet Changer
Pallet Size: 20″ × 12.75″
Pallet Change Time: Approx. 8 Seconds
Max Table Load: 700 Lbs
Tool Changer: Side-Mount 24+1 ATC
Max Tool Diameter: 3″–3.6″
Max Tool Length: 16″
Max Tool Weight: 12 Lbs
Tool-To-Tool: Approx. 2.2 Seconds
Chip-To-Chip: Approx. 4.8 Seconds
Machine Weight: Approx. 14,000 Lbs
Overall Dimensions (L×W×H): Approx. 130″ × 134″ × 113″
Air Requirement: 100 PSI, 9 SCFM
Coolant Capacity: 55 Gallons
Equipped With:
Haas CNC Control
Thru Spindle Coolant
Dual Pallets
