Description
X-Axis: 30″
Y-Axis: 16″
Z-Axis: 20″
Spindle Nose to Table: 4″-24″
Spindle Speed: 12,000 RPM
Spindle Motor: 30 HP
Taper: CAT 40
Table Size: 36″x14″
Max. Weight on Table: 1,500 lbs
Max. Cutting Speed: 833 ipm
X, Y, & Z Axis Rapid Speeds: 1400 ipm
Dimensions: 98″x91″x100″
Weight: 8,380 lbs
Feed Cutting Hours: 471:02
Equipped With:
Haas Control
Through Spindle Coolant
WIPS Probe System
Multi-Auger Chup Removal System
Auto Window
Automatic Coolant Refill
High Pressure Coolant
Programmable Coolant
High Speed Machining
Chip Strainer
*2023 Haas UMC-750 and Trinity AX2-24 Duo Pallet System also available with this machine at additional cost
