Description
Maximum Reach: 3,100 mm
Rated Payload: 150 kg
Suppl. Load, Arm/link Arm/Rotating Col: 50/100/300 kg
Suppl. Load, Arm + Link Arm: Max. 100 kg
Maximum Total Load: 550 kg
Number Of Axes: 6
Mounting Position Shelf-Mounted, Floor
Variant Cleanroom, Foundry
Positioning repeatability: ±0.06 mm
Controller: KR C2 Edition 2005
Approx Weight (Excluding Controller): 1,445 kg
Temperature During Operation: +10 °C to +55 °C
Protection Classification: IP 65
Robot Footprint: 1,006 mm x 1,006 mm
Connection: 7.3 kVA
Noise level: < 75 dB
Axis 1 (A1): ±185° 96°/s
Axis 2 (A2): +70°/–120° 96°/s
Axis 3 (A3): +155°/–119° 95°/s
Axis 4 (A4): ±350° 171°/s
Axis 5 (A5): ±125° 171°/s
Axis 6 (A6): ±350° 238°/s
2 Units Available.
