Description
Longitudinal Travel (X-Axis): 22″
Vertical Travel (Y-Axis): 20.08″
Spindle Travel (Z-Axis): 22.08″
Pallet Dimensions: 15.7″ x 15.7″
Maximum Pallet Load: 880 LBS
Number of Pallets: 2
Number of Index Positions: 360
Rapid Traverse, All Axes: 1180 IPM
Spindle Horsepower: 10 HP
Spindle Speed Range: 35-10000 RPM
Spindle Taper: #40 ISO
Number of Tool Stations: 30
Approximate Floorspace Dimensions: 167″ x 205″
Approximate Machine Height: 114″
Approximate Machine Weight: 12,000 LBS
Equipped With:
30 Position Automatic Tool Changer
Chip Conveyor
