Description
Material Capacities (Mild Steel):
Burring/Turning/Wiring/Bending: 14 gauge
Crimping: 16 gauge
Slitting: 12 gauge
Circle Cutting Thickness: 12 gauge
Circle Cutting Diameter Range: 6″ to 18″
Flanging Thickness: 14 gauge
Flanging Diameter Range: 13″ to 48″
Maximum Flange Height: ¾”
Roller & Frame Dimensions:
Shaft Diameter: 1 7/8″
Distance Between Shaft Centers: 3 ½”
Distance from Roll Center to Frame: 12 ¼”
Length of Shaft Ends for Rolls: 3″
Operating Speed: 15 feet per minute
Motor: 1 HP, 230/460V, 3-phase
Approx. Dimensions: 22″ x 42″ x 64″
Approx. Weight: 1,000 lbs
