Description
X Travel – 30″
Y Travel – 16.14″
Z Travel – 17.72″
Table – 39.37” x 20.08”
Table Load Capacity – 1100 lbs.
Table Top to Spindle Nose – 25.59”
Feed Rates (all axes) – 160 IPM
Rapid Traverse X&Y – 59 IPM
Rapid Traverse Z – 511 IPM
ATC Capacity – 20
Tool Change Time (Tool to Tool) – 4.5 Seconds
Spindle Motor HP – 10 / 7.5
Spindle Speeds – 6000 RPM
Spindle Taper – 40 CAT
Approx Dimensions 102” x 105” x 107″
Approx Weight – 12,760 Lbs.
