Description
Average power – 30 W
Wavelength – 064 – 1085 nm
Working frequency – 30-60 kHz
Impulse duration < 120 ns
Peak power 8,5 kW
Pulse energy 1 mJ
Beam quality <1,8 M²
Z axes stroke 290 mm
Z axes precision 0,05 mm
Repeatability 0,02 mm
Max piece weight 25 kg
Power supply 230 V ± 15% 50/60 Hz 1ph
Cooling system Air
Power absorption 0,8 kW
Dimensions (LxDxH) 560 mm x 760 mm x 770 mm
Weight 85 kg
