Description
Maximum Sheet Width 1500 mm (60”)
Material Thickness 0.4 – 1.1 mm (0.016”– 0.043”) galvanized steel
0.4 – 0.6 mm (0.016”– 0.024”) stainless steel
0.5 – 1.1 mm (0.020”– 0.043”) aluminium
Cutting Speed 2 – 10 m / min. (6 – 32 fpm)
Segment Angle 5 – 46° (in steps of 1 / 10 degree)
Elbow Diameter 100 – 1500 mm (in steps of 1 mm) (4”– 60”)
Number of Cutters 1 – 4 (selectable on control panel)
Designed for fast and automatic rolling of
bend segments, T-pieces, connectors etc
