Description
Trumpf TruPulse 62 Solid State, Pulsed Laser, 3,5 kW, 2021
– Used for spot and seam welding in thermally sensitive applications by using high-energy pulses in short bursts
– Laser power at the workpiece: 60 W / 65 W
– Maximum peak pulse power: 3 kW / 5 kW
– Beam quality: 8 mm – mrad
– Wavelength: 1064 nm
– Adjustable pulse duration: 0.2 ms – 50 ms
– Maximum pulse repetition frequency: 909 Hz
– Maximum pulse energy: 20 J / 50 J
– Minimum laser light cable diameter: 200 μm
