Description
Equipment Overview
The York YCUL0072EE is a 72-ton commercial rooftop air-cooled chiller designed for high-capacity HVAC applications in light industrial and commercial environments. The unit features dual refrigeration circuits for staging and redundancy, runs on R-410A, and is ASHRAE 90.1 compliant. This 2019 unit includes a factory-installed fused disconnect and appears to have been outdoor-stored on pad mounts, with fair external condition.
Key Features and Specifications
Tonnage: 72 tons
Refrigerant: R-410A
Electrical: 460V / 3 PH / 60 Hz
Compressor system: Dual-circuit
Compressors: (2) 17.5 A / 187 LRA
Full load amps: 34 A
Max overcurrent protection: 146 A
Control power: 115V internal transformer
Disconnect: Fused handle installed
Construction: Outdoor enclosure, panel access, top-discharge fans
Compliance: ETL listed, ASHRAE 90.1
Unit weight: 4,002 lbs
